Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
1 / 5
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine
Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine

Solar Panel Making Machine PV Module Oil Heating Vacuum Laminating Machine

Customization: Available
After-sales Service: Life Time
Warranty: 1 Year
Send Inquiry

Product Description

Technical Specifications
Production Scope
Parts Production Line
Automation
Full Automation
Transmission Type
Flexible
Production Line
Comprehensive Automatic
Certification
CE, ISO
Flexible Production
Intelligent Manufacturing
Rhythm
Flow Production Line
Transport Package
Frame Container
Specification
1800*2200mm
HS Code
848640
Production Capacity
100 Set/Sets Per Year
Packaging & Delivery
Package Size
250.00cm * 240.00cm * 150.00cm
Gross Weight
4600.000kg
Product Description

Negotiate the price according to specific circumstances

PV Module Laminating Machine
Solar Panel Making Machine
Technical Parameters
Power AC380v/3phases/4Lines Capacity 3-9(1-3shift)MW/year
Noise at work <65dB Vacuum Rate 200m³/H
Normal Power 9.5KW Max.Power 35KW
Compressed air flux 500L/min Lamination Area 1800*2200mm
Air pressure 0.6-0.8Mpa Temp Uniformity ≤±2ºC
Dimension 2380*2210*1200mm Weight 4.5T
Key Characteristics
⚙️
Integrated Design

Patented design where vacuum and oil pumps are placed inside the machine to save plant space.

🔇
Lower Noise

Using imported vacuum technology to reduce noise to 65dB for a comfortable environment.

🍃
Smoke-Free Operation

Unique smokeless pump design eliminates the need for complex exhausting systems.

⚡
Energy Saving

High efficiency design achieves approximately 30% energy savings compared to other brands.

✅
CE Certified

All machines in the PV production line have passed rigorous CE certification standards.

Machine Detail 1
Machine Detail 2
Machine Detail 3
Machine Detail 4
Frequently Asked Questions
What is the annual production capacity of this laminating machine?
The machine has a capacity of 3-9 MW per year, depending on the number of shifts (1-3 shifts) operated.
What is the maximum lamination area supported?
The standard lamination area for this model is 1800mm * 2200mm.
Does the machine require an external exhausting system for smoke?
No, the machine features a unique smokeless pump design, so you do not need to configure an external exhausting system.
How does this machine contribute to energy efficiency?
Our design is optimized for power consumption, offering approximately 30% energy savings compared to conventional brands.
What certifications does the equipment carry?
All machines in our PV production line are CE and ISO certified, ensuring compliance with international safety and quality standards.
What is the noise level during operation?
The machine operates at a very low noise level of less than 65dB, thanks to high-quality imported vacuum pumps.
