Negotiate the price according to specific circumstances
| Power | AC380V/50HZ/3Phases/5Lines | Capacity | 5-15(1-3shift)MW/year |
| Compressed Air Flow | 0.25m³/min | Vacuum Rate | 100m³/H |
| Normal Power | 10KW | Max. Power | 34KW |
| Lamination Time | PVB/EVA: 12-15min | Lamination Area | 2200*2140mm |
| Working Temperature | 100-160ºC | Temp. Uniformity | ≤±2ºC |
| Dimension | 7700*2620*1350mm | Weight | 7.5T |
Patented design where the vacuum pump and oil pump are placed inside the machine, significantly saving plant space.
Equipped with high-quality imported vacuum pumps, reducing noise levels to 65dB for a more comfortable working environment.
Unique smokeless pump design eliminates the need for a complex exhausting system configuration.
Achieves approximately 30% energy savings compared to other standard brands in the industry.
All machines in the PV production line have successfully passed CE certification standards.
A: The machine offers a capacity of 5-15 MW per year, depending on whether it is operated in 1, 2, or 3 shifts.
A: No, thanks to the unique smokeless pump design, you do not need to configure an additional exhausting system.
A: This machine is designed to handle both PVB and EVA lamination materials with a processing time of 12-15 minutes.
A: By placing the vacuum and oil pumps inside the machine, it saves valuable floor space and simplifies the plant layout.
A: The machine maintains a high temperature uniformity of ≤±2ºC within a working range of 100-160ºC.
A: Yes, all machines in our PV production line have passed the CE certification, ensuring compliance with safety and quality standards.
